Handheld Potentiostat/Galvanostat, Electrochemical Analyzer (MedPstat 2.0 Advance)

  • Handheld Affordable & Potentiostat/Galvanostat
  • Applied Potential Range: ± 10 V
  • Max Current Range: 250 mA
  • Measured Potential Range (Gal): ±15 V
  • USB Communication
  • Software for PC Data acquisition & plotting
Categories ,

MedPstat 2.0 Advance is a Portable, Affordable, & Precision Potentiostat/Galvanostat with a wide range of ± 10V, 250 mA. Optimum for electrochemistry research applications. Included is a high-quality dummy cell for learning & calibration applications and lifetime access to free software – MedEplot for PC, data acquisition & plotting.

Detailed Specifications:

Parameter Values
Electrochemical Methods CV, LSV, ChronoAmp, OCP, DPV, SWV, ChronoPot, Charge-Discharge, Corrosion Analysis (Tafel), Corrosion Analysis (Polarization Resistances)
Channels Per Unit 1
Applied potential range ± 10 V
Applied Potential Accuracy 0.1% of the setpoint, 1mV Max
Applied Potential Resolution 345 µV
Measured Potential Accuracy 0.1% of the setpoint, 1mV Max
Measured Potential Resolution 312 µV
Compliance Voltage ± 15 V
Maximum Current 250 mA
Current ranges 7 Ranges (10nA to 250mA)
Measured Current Accuracy 1% of the range, 100pA max
Measured Current Resolution 0.03% of range, 3 pA
Applied Current Resolution (Gal) 3.45 nA
Measured Potential Range (Gal) ± 10 V
Input Impedance > 10 TΩ
Input Bias Current 1pA Max
Computer Interface / Communication USB
Channel Cable Length 0.8 meters
Power Supply / Requirements 24V DC / 100V – 240V AC
Weight 320 grams
Physical Dimensions 181mm * 91.5mm * 42mm
Operating temperature range 0 to 50°C
PC Software Available with a lifetime license
Bandwidth up to 10 MHz
Max. data acquisition rate 1 KHz
ADC/DAC Resolution 16 bit
Slew Rate (No Load) 45V/µs
Maximum ADC Sampling Speed 5,00,000 samples/sec
