Three Electrode Split Test Cell
- Precise 3-electrode measurement for accurate voltage monitoring
- Adjustable 0.1-1 mm thickness fits variouselectrodes and separators
- Corrosion-resistant stainless steel with PTFE seals
- Glove-box compatible for controlled environments
- Universal compatibility with liquid, gel, and solid electrolytes
Product Description
Accelerate your battery research with the Three Electrode Split TestCell—a precision-engineered, fully customizable testing solution designed for advanced electrochemical analysis. Built for researchers who demand accuracy and flexibility, this cell enables detailed performance evaluation of electrode materials under realistic conditions. Whether you’re developing next-generation lithium-ion batteries or testing novel electrolytes, this compact, corrosion-resistant cell delivers reliable data in a glove-box-friendly format.
|
Specifications |
|
|
Model |
Three – Electrode Split Test Cell |
|
Body Material |
Stainless Steel |
|
Sealing System |
PTFE O-rings & Sealing Nut |
|
Thickness Range |
0.1–1.0 mm (adjustable) |
|
Guide Sleeve Size |
15 mm (inner) × 24 mm (outer) |
|
Pressure Plate |
15 mm metal plates (top & bottom) |
|
Spring System |
Adjustable compression spring with locking nut |
|
Operating Environment |
Glove box compatible |
|
Ideal Applications |
Li-ion, solid-state, and aqueous battery R&D |
